ASUS RS720A-E11-RS12E Socket SP3 Rack (2U) Silver
- Powered by AMD EPYC 7003 processor with 64 cores, 128 threads and support for a maximum TDP of up to 280 watts per socket
- GPU-optimized design allows four dual-slot or eight single-slot GPUs for AI workloads
- A total of 12 storage bays in combination of NVMe/SATA/SAS drives on front panel to enable extensive storage and high-throughput performance
- Up to nine PCIe® 4.0 slots to enable higher bandwidth and improved data-transfer rates
- Flexible onboard LAN-module design to enable four 1 Gb LAN or two 10 Gb LAN options
- Flexible air and liquid cooling solution achieves lower power-usage effectiveness (PUE) and optimized TCO for data centers
- Onboard ASUS ASMB10-iKVM for out-of-band management with ASPEED AST2600 controller
- Integrated PFR FPGA as the platform Root-of-Trust solution for firmware resiliency
- High power efficiency with redundant 1600W 80 Plus Titanium and Platinum power supplies
| Processor | |
|---|---|
| Processor socket | Socket SP3 |
| Built-in processor | Yes |
| Memory | |
|---|---|
| Supported RDIMM clock speeds | 2933,3200 MHz |
| Supported DIMM module capacities | 16GB, 32GB, 64GB, 128GB |
| Supported memory types | DDR4-SDRAM |
| Number of DIMM slots | 32 |
| Graphics | |
|---|---|
| On-board graphics card memory | 64 MB |
| On-board graphics card model | Aspeed AST2600 |
| Ports & interfaces | |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84714100 |
| Design | |
|---|---|
| Product colour | Silver |
| Chassis type | Rack (2U) |
| Power | |
|---|---|
| 80 PLUS certification | 80 PLUS Platinum |
| AC input frequency | 50 – 60 Hz |
| AC input voltage | 220 – 240 V |
| Power supply | 1600 W |
