ATEN CS84A KVM switch Silver
- One PS/2 console controls 4 computers.
- Computer selection via front panel pushbuttons and hotkeys.
- Superior video quality- up to 1920 x 1440; DDC2B.
- Supports Microsoft IntelliMouse, Logitech MouseMan, FirstMouse and IBM Scrollpoint Mouse.
- Compact, Sturdy, Durable Metal Housing.
- Keyboard and mouse emulation for error free booting.
- Auto Scan function to monitor computer operation.
- Bus-Powered.
- OS Support:Windows 2000, Windows XP, Windows Vista, LINUX, Mac and FreeBSD
CS84A is a KVM Switch with built-in PS/2 on each of the front and rear panels. It can control 4 servers via a single console and allows users to switch between computers via the buttons on the front panel of the switch or the hotkey configuration on the keyboard. It is the simplest and most convenient most convenient solution for multi-computer management.
| Ports & interfaces |
| Video port type |
VGA |
| Mouse port type |
PS/2 |
| Keyboard port type |
PS/2 |
| Number of computers controlled |
4 |
| Performance |
| Maximum resolution |
1920 x 1440 pixels |
| Design |
| Product colour |
Silver |
| Power |
| Power consumption (typical) |
1.17 W |
| Operational conditions |
| Operating relative humidity (H-H) |
0 – 80% |
| Storage temperature (T-T) |
-20 – 60 °C |
| Operating temperature (T-T) |
0 – 50 °C |
| Weight & dimensions |
| Weight |
640 g |
| Other features |
| Ports quantity |
4 |
| Dimensions (WxDxH) |
210 x 87 x 55 mm |
| Power supply type |
DC9V |
| Connectivity technology |
Wired |
