iiyama ProLite XUB2390HS-B1 LED display 58.4 cm (23″) 1920 x 1080 pixels Full HD Black
- 58.4 cm (23″) LED AH-IPS
- Full HD 1920 x 1080 pixels 16:9
- 5 ms 250 cd/m² 1000:1
- E 16 kWh 24 W
ProLite XUB2390HS is a 23” LED monitor with latest IPS Panel technology considered to be the best all round panel type. It offers accurate and consistent colour reproduction with wide viewing angles and a fast response time. A truly ergonomic stand including pivot function makes the XUB2390HS an excellent choice for photographic design, web design, standard office use. It’s the perfect choice for multi-monitor applications.
| Display | |
|---|---|
| Separate H/V sync | Yes |
| 3D | No |
| Viewable size diagonal | 58.4 cm |
| Viewable size, vertical | 28.6 cm |
| Viewable size, horizontal | 50.9 cm |
| Vertical scan range | 56 – 75 Hz |
| Horizontal scan range | 24 – 80 kHz |
| Pixel pitch | 0.265 x 0.265 mm |
| Display number of colours | 16.78 million colours |
| Viewing angle, vertical | 178° |
| Viewing angle, horizontal | 178° |
| Contrast ratio (dynamic) | 5000000:1 |
| Contrast ratio (typical) | 1000:1 |
| Aspect ratio | 16:9 |
| Supported graphics resolutions | 1920 x 1080 (HD 1080) |
| Screen shape | Flat |
| Display surface | Matt |
| Response time | 5 ms |
| Display brightness (typical) | 250 cd/m² |
| Panel type | AH-IPS |
| HD type | Full HD |
| Touchscreen | No |
| Display technology | LED |
| Native aspect ratio | 16:9 |
| Display resolution | 1920 x 1080 pixels |
| Display diagonal | 58.4 cm (23″) |
| Multimedia | |
|---|---|
| RMS rated power | 4 W |
| Number of speakers | 2 |
| Built-in speaker(s) | Yes |
| Design | |
|---|---|
| Product colour | Black |
| Market positioning | Business |
| Ports & interfaces | |
|---|---|
| HDCP | Yes |
| Audio input | Yes |
| HDMI ports quantity | 1 |
| DVI-D ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Ergonomics | |
|---|---|
| Plug and Play | Yes |
| Number of OSD languages | 9 |
| On Screen Display (OSD) languages | Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Polish, Russian |
| On Screen Display (OSD) | Yes |
| Tilt angle range | -4 – 20° |
| Tilt adjustment | Yes |
| Swivel angle range | -45 – 45° |
| Swivelling | Yes |
| Pivot angle | 0 – 90° |
| Pivot | Yes |
| Adjustable height (max) | 13 cm |
| Height adjustment | Yes |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Panel mounting interface | 100 x 100 mm |
| VESA mounting | Yes |
| Power | |
|---|---|
| European Product Registry for Energy Labelling (EPREL) code | 356022 |
| Energy efficiency scale | A to G |
| AC input frequency | 50 – 60 Hz |
| AC input voltage | 100 – 240 V |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 24 W |
| Energy consumption (SDR) per 1000 hours | 16 kWh |
| Energy efficiency class (SDR) | E |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 5 – 85% |
| Operating relative humidity (H-H) | 10 – 80% |
| Storage temperature (T-T) | -20 – 60 °C |
| Operating temperature (T-T) | 5 – 35 °C |
| Weight & dimensions | |
|---|---|
| Height (without stand) | 317.5 mm |
| Depth (without stand) | 44 mm |
| Width (without stand) | 532.5 mm |
| Weight (with stand) | 5.4 kg |
| Height (with stand) | 393.5 mm |
| Depth (with stand) | 230 mm |
| Width (with stand) | 532.5 mm |
| Packaging content | |
|---|---|
| Quick start guide | Yes |
| Cables included | AC, Audio (3.5mm), DVI |
| Stand included | Yes |
| Sustainability | |
|---|---|
| Sustainability certificates | EPEAT Silver, ENERGY STAR |
| General | |
|---|---|
| Product family | ProLite |
| Other features | |
|---|---|
| Certification | TCO 6, CE, TÜV-Bauart, VCCI-B, CU |
| Power management | Yes |
| TV tuner integrated | No |
| Rotating | Yes |
| Built-in subwoofer | No |
| On/off switch | Yes |
| Display | LED |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85285210 |
