Intel Core i7-7700T processor 2.9 GHz 8 MB Smart Cache
- Intel® Core™ i7 i7-7700T 2.9 GHz
- 8 MB Smart Cache LGA 1151 (Socket H4)
- Processor cores: 4 14 nm 64-bit 35 W
- Maximum internal memory supported by processor: 64 GB DDR4-SDRAM, DDR3L-SDRAM
- On-board graphics card Intel® HD Graphics 630
The Last Word in PC Performance
More power, more battery-life, and more high-quality entertainment – with the Intel® Core™ i7 processor, you get more of what makes a PC great.
Equipped with Intel® Turbo Boost Technology 2.0 , your PC will have the unprecedented power and responsiveness to help your productivity soar. Smooth streaming and HD entertainment enable immersive, full screen 4K and 360 experiences for incredibly vivid gaming and remarkable viewing. Plus, you will wield the power to create, edit, and share 4K content – all with the lightning speed data transfers of Thunderbolt™ 3. It’s PC performance and versatility like never before.
The Speed You Need
Equipped with rapid responsiveness, the 7th generation Intel® Core™ processor has the power and speed to keep up with your demands. Open files and programs quickly, plus seamlessly switch between applications and web pages without delay.
Immersive Entertainment
Experience ultra high-definition content with the clarity and sharpness of 4K resolution. Featuring 4x more pixels than full HD screens, you’ll get crisper, clearer images for an immersive viewing like never before.
Hassle Free
Today’s PCs are more hassle-free than ever – log in quickly and easily with facial recognition technology, get 0.5 second wake, and never feel weighed down with new razor-thin devices.
| Processor | |
|---|---|
| Generation | 7th Generation |
| Processor ARK ID | 97122 |
| Processor code | SR339 |
| Processor codename | Kaby Lake |
| Bus type | DMI3 |
| Stepping | B0 |
| Compatible chipsets | Intel® B150, Intel® H110, Intel® H170, Intel Q150, Intel® Q170, Intel® Z170 |
| Configurable TDP-down | 25 W |
| Configurable TDP-down frequency | 1.9 GHz |
| Thermal Design Power (TDP) | 35 W |
| Processor cache type | Smart Cache |
| Processor cache | 8 MB |
| Processor boost frequency | 3.8 GHz |
| Processor operating modes | 64-bit |
| System bus rate | 8 GT/s |
| Processor threads | 8 |
| Processor series | Intel Core i7-7700 Desktop series |
| Component for | PC |
| Cooler included | No |
| Box | No |
| Processor lithography | 14 nm |
| Processor socket | LGA 1151 (Socket H4) |
| Processor cores | 4 |
| Processor base frequency | 2.9 GHz |
| Processor model | i7-7700T |
| Processor generation | 7th gen Intel® Core™ i7 |
| Processor family | Intel® Core™ i7 |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | No |
| Memory channels | Dual-channel |
| Memory voltage supported by processor | 1.35 V |
| Memory clock speeds supported by processor | 1333,1600,2133,2400 MHz |
| Memory types supported by processor | DDR4-SDRAM, DDR3L-SDRAM |
| Maximum internal memory supported by processor | 64 GB |
| Graphics | |
|---|---|
| On-board graphics card ID | 5912 |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP – Integrated Flat Panel) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 24 Hz |
| On-board graphics card maximum resolution (DisplayPort) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (eDP – Integrated Flat Panel) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2304 pixels |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card 4K support | Yes |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics card dynamic frequency (max) | 1150 MHz |
| On-board graphics card base frequency | 350 MHz |
| Maximum on-board graphics card memory | 64 GB |
| On-board graphics card model | Intel® HD Graphics 630 |
| On-board graphics card | Yes |
| Features | |
|---|---|
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| Export Control Classification Number (ECCN) | 5A992C |
| Scalability | 1S |
| Embedded options available | Yes |
| PCI Express CEM revision | 3.0 |
| CPU configuration (max) | 1 |
| Thermal solution specification | PCG 2015A |
| Supported instruction sets | SSE4.1, SSE4.2, AVX 2.0 |
| PCI Express configurations | 1×16, 2×8, 1×8+2×4 |
| PCI Express slots version | 3.0 |
| Maximum number of PCI Express lanes | 16 |
| Market segment | Desktop |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Processor special features | |
|---|---|
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Secure Key Technology version | 1.00 |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Stable Image Platform Program (SIPP) version | 1.00 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Secure Key | Yes |
| Intel Clear Video Technology | Yes |
| Intel TSX-NI | Yes |
| Intel® OS Guard | Yes |
| Intel® Optane™ Memory Ready | Yes |
| Intel Enhanced Halt State | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
| Intel® Boot Guard | Yes |
| Intel TSX-NI version | 1.00 |
| Conflict-Free processor | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® Turbo Boost Technology 2.0 frequency | 3.8 GHz |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Memory Protection Extensions (Intel® MPX) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| General | |
|---|---|
| Product family | Core |
| Product series | i7 |
| Operational conditions | |
|---|---|
| Tjunction | 80 °C |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 8542310001 |
| Technical details | |
|---|---|
| Bus bandwidth | 8 |
| Bus type units | GT/s |
| Maximum resolution & refresh rate (HDMI) | 4096×2304@24Hz |
| Maximum resolution & refresh rate (Integrated Flat Panel) | 4096×2304@60Hz |
| Processor brand name | 7th Gen Intel Core i7 processors |
| Last change | 63903513 |
| Product family | 7th Generation Intel Core i7 Processors |
| Launch date | Q1’17 |
| Status | Launched |
| Maximum resolution & refresh rate (DisplayPort) | 4096×2304@60Hz |
| Maximum memory | 64 GB |
| Bus speed | 8 GT/s |
| Processor ID | 0x5912 |
| Processor cache | 8192 KB |
| Supported memory types | DDR4-SDRAM, DDR3L-SDRAM |
| Product type | Processor |
| Maximum graphics card memory | 64 GB |
| Packaging data | |
|---|---|
| Package type | Retail box |
| Package height | 101 mm |
| Package depth | 116 mm |
| Package width | 70 mm |
| Weight & dimensions | |
|---|---|
| Processor package size | 37.5 x 37.5 mm |
| Other features | |
|---|---|
| Video decoding | Yes |
| Maximum internal memory | 64 GB |
