Intel Pentium G4560 processor 3.5 GHz 3 MB
- Intel Pentium G G4560 3.5 GHz
- 3 MB LGA 1151 (Socket H4)
- Processor cores: 2 14 nm 64-bit 54 W
- Maximum internal memory supported by processor: 64 GB DDR4-SDRAM, DDR3L-SDRAM
- On-board graphics card Intel® HD Graphics 610
Exceptional Performance for Work, Play, and Beyond
Prime yourself for more of everything you want and need. The latest Intel® Pentium® processors let you stream, share, shop, play, create, and consume—all at the same time.
Discover a new dimension in productivity with Intel’s next-generation Pentium® processors. Performance optimized to accelerate portable 2 in 1s, laptops, towers, desktops, and All-in-Ones. Go thinner, sleeker, and smaller with reliability you can count on.
Featuring Splendid Audiovisuals
Whether you are streaming Ultra HD video to a big screen or simply reading the news, get impressive multimedia and entertainment features in a wide range of devices with the latest Intel® Pentium® processors.
Chat, Shop, or Surf in Style
Get exceptional computing performance to keep your life moving. Browse the web, shop, and communicate with friends simultaneously. With improved graphics, light weight and low-power consumption, witness a processor built for better experiences.
Whatever You Do, Do It Faster
The new Intel® Pentium® processor has improved functionality for multitasking, helping you get more work done with less stress. Create, edit, and organize critical documents while managing photos and staying on top of emails.
Never Stop Playing
The Intel® Pentium® features upgraded graphics and computing performance to juice up your casual gaming life. Level up your enjoyment with more seamless action and snappier gameplay experiences.
| Processor | |
|---|---|
| Processor ARK ID | 97143 |
| Processor code | SSSSR32Y |
| Processor codename | Kaby Lake |
| Bus type | DMI3 |
| Stepping | B0 |
| Thermal Design Power (TDP) | 54 W |
| Processor cache | 3 MB |
| Processor operating modes | 64-bit |
| System bus rate | 8 GT/s |
| Processor threads | 4 |
| Processor series | Intel Pentium G4500 Series For Desktop |
| Component for | PC |
| Cooler included | No |
| Box | No |
| Processor lithography | 14 nm |
| Processor socket | LGA 1151 (Socket H4) |
| Processor cores | 2 |
| Processor base frequency | 3.5 GHz |
| Processor model | G4560 |
| Processor family | Intel Pentium G |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | Yes |
| Memory channels | Dual-channel |
| Memory voltage supported by processor | 1.35 V |
| Memory clock speeds supported by processor | 1333,1600,2133,2400 MHz |
| Memory types supported by processor | DDR4-SDRAM, DDR3L-SDRAM |
| Maximum internal memory supported by processor | 64 GB |
| Graphics | |
|---|---|
| On-board graphics card ID | 0x5902 |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP – Integrated Flat Panel) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 24 Hz |
| On-board graphics card maximum resolution (DisplayPort) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (eDP – Integrated Flat Panel) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2304 pixels |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.4 |
| On-board graphics card 4K support | Yes |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics card dynamic frequency (max) | 1050 MHz |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card outputs supported | DisplayPort, Embedded DisplayPort (eDP), HDMI |
| Maximum on-board graphics card memory | 64 GB |
| On-board graphics card model | Intel® HD Graphics 610 |
| On-board graphics card | Yes |
| Features | |
|---|---|
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| Export Control Classification Number (ECCN) | 5A992C |
| Scalability | 1S |
| Embedded options available | No |
| PCI Express CEM revision | 3.0 |
| Graphics & IMC lithography | 14 nm |
| CPU configuration (max) | 1 |
| Thermal solution specification | PCG 2015C |
| Supported instruction sets | SSE4.1, SSE4.2 |
| PCI Express configurations | 1×16, 2×8, 1×8+2×4 |
| PCI Express slots version | 3.0 |
| Maximum number of PCI Express lanes | 16 |
| Market segment | Desktop |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Processor special features | |
|---|---|
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Secure Key Technology version | 1.00 |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Stable Image Platform Program (SIPP) version | 0.00 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Secure Key | Yes |
| Intel Clear Video Technology | Yes |
| Intel TSX-NI | No |
| Intel® OS Guard | Yes |
| Intel® Optane™ Memory Ready | No |
| Intel Enhanced Halt State | Yes |
| Intel® vPro™ Platform Eligibility | No |
| Intel® Boot Guard | Yes |
| Intel TSX-NI version | 0.00 |
| Conflict-Free processor | Yes |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel® Transactional Synchronization Extensions | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | No |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Memory Protection Extensions (Intel® MPX) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| General | |
|---|---|
| Product family | Pentium |
| Product series | G |
| Operational conditions | |
|---|---|
| Tjunction | 100 °C |
| Technical details | |
|---|---|
| Bus bandwidth | 8 |
| Bus type units | GT/s |
| Maximum resolution & refresh rate (HDMI) | 4096×2304@24Hz |
| Maximum resolution & refresh rate (Integrated Flat Panel) | 4096×2304@60Hz |
| Processor brand name | Intel Pentium |
| Last change | 63903513 |
| Product family | Intel Pentium Processor |
| Launch date | Q1’17 |
| Status | Discontinued |
| Maximum resolution & refresh rate (DisplayPort) | 4096×2304@60Hz |
| Maximum memory | 64 GB |
| Bus speed | 8 GT/s |
| Processor ID | 0x5902 |
| Processor cache | 3072 KB |
| Supported memory types | DDR4-SDRAM, DDR3L-SDRAM |
| Product type | Processor |
| Maximum graphics card memory | 64 GB |
| Packaging data | |
|---|---|
| Package type | Retail box |
| Package weight | 337 g |
| Package height | 101 mm |
| Package depth | 116 mm |
| Package width | 70 mm |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 8542310001 |
| Weight & dimensions | |
|---|---|
| Processor package size | 37.5 x 37.5 mm |
| Other features | |
|---|---|
| Video decoding | Yes |
| Maximum internal memory | 64 GB |
