Mellanox Technologies MSN2410-BB2F network switch Managed 1U Black
- Managed Web-based management
- Configuring Location Settings (CLI)
- Switching capacity: 4000 Gbit/s
- 1U Rack mounting
The SN2410 provides the most predictable, highest performance 100GbE ToR switching platform for the growing demands of today’s data centers. The SN2410 switch is an ONIE (Open Network Install Environment) based platform for allowing a multitude of operating systems to be mounted on it and utilizing the advantages of Open Networking and the capabilities of the Mellanox Spectrum ASIC.
The SN2410 switch is an ideal top-of-rack (ToR) solution, allowing maximum flexibility, with port Max Speeds spanning from 10Gb/s to 100Gb/s per port. Its optimized port configuration enables high-Max Speed rack connectivity to any server at 10GbE or 25GbE Max Speeds. The 100GbE uplink ports allow a variety of blocking ratios that suit any application requirement. Powered by the Spectrum ASIC and packed with 8 ports running at 100GbE (can be split to 16 ports running 50GbE) and 48 ports running at 25GbE, the SN2410 carries a whopping throughput of 4Tb/s with a landmark 5.95Bpps processing capacity in a compact 1RU form factor.
| Management features |
| Configuring Location Settings (CLI) |
Yes |
| Web-based management |
Yes |
| Switch type |
Managed |
| Ports & interfaces |
| Power connector |
AC-in jack |
| Fiber optic connector |
QSFP28, SFP28 |
| QSFP+ module slots quantity |
8 |
| Installed SFP+ modules quantity |
48 |
| Basic switching RJ-45 Ethernet ports type |
No |
| Network |
| Link aggregation |
Yes |
| Spanning tree protocol |
Yes |
| Port mirroring |
Yes |
| Zero Touch Provisioning (ZTP) |
Yes |
| Optical fiber |
| Switching optical modules type |
100 Gigabit Ethernet |
| Data transmission |
| Jumbo frames support |
Yes |
| Store-and-forward |
Yes |
| Throughput |
5950 Mpps |
| Switching capacity |
4000 Gbit/s |
| Security |
| Loop protection |
Yes |
| BPDU filtering/protection |
Yes |
| Root protection |
Yes |
| Design |
| Product colour |
Black |
| Form factor |
1U |
| Rack mounting |
Yes |
| Power |
| Power consumption (typical) |
165 W |
| Input current |
4.5 A |
| AC input frequency |
50 – 60 Hz |
| AC input voltage |
200 – 240 V |
| Number of power supply units |
2 |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
No |
| Weight & dimensions |
| Weight |
8.52 kg |
| Height |
43.8 mm |
| Depth |
436 mm |
| Width |
438 mm |
