StarTech.com 2-Port Multi Monitor Adapter – USB-C to 2x HDMI Video Splitter – USB Type-C to HDMI MST Hub – Dual 4K 30Hz or 1080p 60Hz – Thunderbolt 3 Compatible – Windows Only
- MULTI-MONITOR CONFIGURATION: USB Type-C to Dual HDMI adapter/splitter hub drives up to 2x 4K 30Hz or 2x 1080p 60Hz HDMI monitors using a USB C DP Alt-Mode port on Windows laptops; TB3/TB4/USB4 Compatible; Not compatible with macOS
- NO DRIVERS OR SOFTWARE: Increase productivity by adding two extended or mirrored displays to a Windows laptop; Utilize integrated or discrete GPU (Intel/AMD/Nvidia) capabilities enabling high performance graphics with minimal CPU usage
- HARDWARE COMPATIBILITY: Host system must support DP Alt Mode 1.2 / HBR2 / MST; Please verify maximum number of displays supported by your GPU; Some GPU chips (such as Intel HD Graphics) are only capable of supporting a maximum of three displays
- Extra-Long CABLE: 1ft (30 cm) built-in cable for extended reach reduces port/connector strain on 2-in-1 devices like Surface Pro 7, HP Elite x2/laptops on riser stands; Ideal for on-the-go travel use in office/home office/shared workspaces
- OUR ADVANTAGE: Included connectivity tools for IT Pro’s and IT help-desk support teams with Windows Layout Utility which restores windows app locations when re-connecting the USBC to Dual HDMI Adapter
Dual Monitor Adapter | Windows | Thunderbolt 3 Compatible
This USB-C to HDMI MST Hub lets you connect two HDMI monitors to your USB Type-C Windows device, conveniently helping you to maximize your productivity.
Multi-tasking Made Easy
With devices becoming more portable than ever, you can be limited to fewer video outputs and confined to your small integrated screen. This multi-stream transport hub solves that problem by enabling you to connect two separate displays to your USB-C computer, making multi-tasking much easier. Using this USB-C to HDMI video splitter, you can mirror your display onto additional monitors or stream independent content to each display, which makes it the ideal accessory for travel or hot-desking.
Astonishing Picture Quality
MST technology uses your existing video card to minimize the use of system resources, while delivering UHD 4K resolutions for two monitors or displays simultaneously. With support for HD 1080p and UHD 4K the USB-C hub is perfect for all high-resolution applications such as graphic design and CAD drawing.
Hassle-Free Setup
Multi-stream transport offers an easy setup by natively working on any Windows device that supports DP Alt Mode over USB Type-C. This USB-C to HDMI hub is Thunderbolt 3 compatible, and offers plug-and-play installation with no drivers or software required. Additionally, this dual-monitor splitter is powered by the USB-C port, meaning no external power cords are necessary.
MSTCDP122HD is backed by a StarTech.com 3-year warranty, and free lifetime technical support.
The StarTech.com Advantage
– MULTIPLE MONITORS: USB-C to HDMI splitter to drive 2x 4K 30Hz or 2x 1080p 60Hz HDMI displays using a USB-C DP Alt-Mode port (DP 1.2/HBR2/MST) w/ no video compression; Thunderbolt 3 compatible
– CONVENIENCE: With a built-in 1ft cable, this bus-powered 2-port MST hub provides an easy method to connect up to two independent screens with any DisplayPort over USB Type-C Windows host device
– COMPATIBLE WITH: Dell XPS / Precision / Latitude, Lenovo ThinkPad X1 Carbon / Extreme, Surface Laptop 3 / Book 3 / Pro 7, HP ProBook / EliteBook / Spectre / ZBook & smaller (Mini -ITX) computers
| Performance | |
|---|---|
| Certification | CE, FCC, REACH |
| Chipset | MegaChips – STDP4320, Parade – PS8402A, VIA/VLI – VL100 |
| Supported graphics resolutions | 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 2560 x 1600 (WQXGA), 3840 x 2160 |
| Refresh rate at maximum resolution | 30 Hz |
| Maximum resolution | 3840 x 2160 pixels |
| HDMI version | 1.4 |
| Number of displays supported | 2 |
| DisplayPort output | No |
| HDMI output | Yes |
| DVI output | No |
| USB connector gender | Male |
| USB connector type | USB Type-C |
| Design | |
|---|---|
| Integrated USB cable | Yes |
| Product colour | Black |
| System requirements | |
|---|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Weight & dimensions | |
|---|---|
| Weight | 44 g |
| Height | 13 mm |
| Depth | 62 mm |
| Width | 58 mm |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 50 – 90% |
| Storage temperature (T-T) | -20 – 60 °C |
| Operating temperature (T-T) | 5 – 35 °C |
| Packaging data | |
|---|---|
| Package weight | 143 g |
| Package height | 32 mm |
| Package depth | 174 mm |
| Package width | 144 mm |
| Packaging content | |
|---|---|
| Quick installation guide | Yes |
| Technical details | |
|---|---|
| Compliance certificates | RoHS |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84733020 |
| Master (outer) case height | 229 mm |
| Master (outer) case length | 504 mm |
| Master (outer) case width | 332 mm |
| Products per master (outer) case | 28 pc(s) |
