TieDex UK D-Link Web Smart DGS-1210-48 – switch – 48 ports – Managed
The DGS-1210-48 is part of D-Link’s 3rd generation of Web Smart Switches that integrates advanced management and security functions for performance and scalability.
With D-link Green technology now in its second generation, the DGS-1210-48 provides a complete, affordable and eco-friendly solution for small and medium businesses (SMB).
D-Link Web Smart DGS-1210-48 – Switch – Managed – 48 x 10/100/1000 + 4 x shared SFP – desktop
Basic Specifications
- Manufacturer’s Part Number
- DGS-1210-48
- EAN
- 7900693324182
- Weight
- 2.3 kg
- Product Description
- D-Link Web Smart DGS-1210-48 – switch – 48 ports – Managed
- Model
- D-Link Web Smart DGS-1210-48
- Dimensions (WxDxH)
- 44 cm x 20.7 cm x 4.4 cm
- Features
- Flow control, Layer 2 switching, DHCP support, auto-negotiation, BOOTP support, RARP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, WRR queuing, store and forward, MAC address filtering, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, STP support, ACL support, QoS, DHCP server, Safeguard Engine, D-Link Green Technology
- Power
- AC 120/230 V (50/60 Hz)
- Device Type
- Switch – 48 ports – Managed
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3az
- MAC Address Table Size
- 16K entries
- Subtype
- Gigabit Ethernet
- Enclosure Type
- 1U
- Remote Management Protocol
- SNMP 1, SNMP 2, Telnet, HTTP, TFTP
- Jumbo Frame Support
- 13000 bytes
- Ports
- 48 x 10/100/1000 + 4 x shared SFP
- Interfaces
- Gigabit Ethernet
General
- Device Type
- Switch – 48 ports – Managed
- Enclosure Type
- Desktop 1U
- Subtype
- Gigabit Ethernet
- Ports
- 48 x 10/100/1000 + 4 x shared SFP
- MAC Address Table Size
- 16K entries
- Jumbo Frame Support
- 13000 bytes
- Remote Management Protocol
- SNMP 1, SNMP 2, Telnet, HTTP, TFTP
- Authentication Method
- RADIUS
- Features
- Flow control, Layer 2 switching, DHCP support, auto-negotiation, BOOTP support, RARP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, WRR queuing, store and forward, MAC address filtering, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, STP support, ACL support, QoS, DHCP server, Safeguard Engine, D-Link Green Technology
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3az
- RAM
- 1 MB
- Built-in Devices
- Led panel
- Status Indicators
- Port transmission speed, power, link OK, link/activity
Dimensions & Weight
- Width
- 44 cm
- Depth
- 20.7 cm
- Height
- 4.4 cm
- Weight
- 2.3 kg
Miscellaneous
- MTBF
- 322,402 hours
- Compliant Standards
- FCC Class A certified, C-Tick, cUL, VCCI Class A ITE, IC Class A
Expansion / Connectivity
- Interfaces
- 48 x 1000Base-T RJ-45 ¦ 4 x SFP (mini-GBIC)
Power
- Power Device
- Internal power supply
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Consumption Operational
- 33.4 Watt
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 50 °C
- Humidity Range Operating
- 10 – 95%
