TieDex UK TP-Link Archer VX1800v V1 – wireless router – DSL modem – Wi-Fi 6 – 3G, 4G – desktop
TP-Link Archer VX1800v V1 – Wireless router – DSL modem 4-port switch – 1GbE – Wi-Fi 6 – Dual Band – 3G, 4G
Basic Specifications
- Manufacturer’s Part Number
- ARCHER VX1800V
- EAN
- 4895252503838
- Manufacturer Warranty
- 3-year warranty
- Weight
- 970 g
- Product Description
- TP-Link Archer VX1800v V1 – wireless router – DSL modem – Wi-Fi 6 – 3G, 4G – desktop
- Model
- TP-Link Archer VX1800v V1
- Dimensions (WxDxH)
- 26.02 cm x 13.5 cm x 4.16 cm
- Features
- NAT support, parental control, WMM support, QoS, DHCP server, Samba support, FTP server, port forwarding, port triggering, 3G/4G USB Dongle Support, DHCP client, DoS, SYN Flooding, VoIP support, Wireless Scheduler, IPMB, Airtime Fairness, port mapping, DMZ support, DynDNS, 2×2 MIMO technology, IPTV support, EasyMesh, Guest Network, Address Reservation, wireless radio enable/disable, MBSSID, RNC technology
- Device Type
- Wireless router – DSL modem – 4-port switch (integrated)
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11k, UPnP, IEEE 802.11ac, IEEE 802.11v, IEEE 802.11ax, Wi-Fi CERTIFIED 6
- Capacity
- VPN tunnels: 10
- Performance
- Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (5 GHz): 1201 Mbps
- Frequency Band
- 2.4 GHz / 5 GHz
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6)
- Enclosure Type
- Desktop
- Routing Protocol
- RIP-1, RIP-2, IGMPv2, IGMP, static IP routing, IGMPv3
- Network / Transport Protocol
- PPTP, L2TP, IPSec, PPPoE, FTP, DHCP, DNS, DDNS
- WAN Ports Qty
- 1
- VoIP Protocols
- SIP, RTP
- Remote Management Protocol
- DHCP, DNS
- Digital Signaling Protocol
- ADSL, VDSL, SIP, ADSL2, ADSL2+, VDSL2
- Generation
- 3G, 4G
General
- Device Type
- Wireless router – 4-port switch (integrated)
- Enclosure Type
- Desktop
- Connectivity Technology
- Wireless, wired
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6)
- Frequency Band
- 2.4 GHz / 5 GHz
- Performance
- Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (5 GHz): 1201 Mbps
- Capacity
- VPN tunnels: 10
- Network / Transport Protocol
- PPTP, L2TP, IPSec, PPPoE, FTP, DHCP, DNS, DDNS
- Routing Protocol
- RIP-1, RIP-2, IGMPv2, IGMP, static IP routing, IGMPv3
- Remote Management Protocol
- DHCP, DNS
- Encryption Algorithm
- WPA-PSK, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise, WPA3-Personal
- Wi-Fi Rating
- AX1800
- Features
- NAT support, parental control, WMM support, QoS, DHCP server, Samba support, FTP server, port forwarding, port triggering, 3G/4G USB Dongle Support, DHCP client, DoS, SYN Flooding, VoIP support, Wireless Scheduler, IPMB, Airtime Fairness, port mapping, DMZ support, DynDNS, 2×2 MIMO technology, IPTV support, EasyMesh, Guest Network, Address Reservation, wireless radio enable/disable, MBSSID, RNC technology
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11k, UPnP, IEEE 802.11ac, IEEE 802.11v, IEEE 802.11ax, Wi-Fi CERTIFIED 6, RoHS
- Status Indicators
- Power, phone, LAN, wireless, Internet, DSL
Communications
- Type
- DSL modem
- Digital Signaling Protocol
- ADSL, VDSL, SIP, ADSL2, ADSL2+, VDSL2
- Generation
- 3G, 4G
- Protocols & Specifications
- ITU G.992.1 (G.DMT), ITU G.992.2 (G.Lite), ITU G.994.1 (G.hs), ITU G.992.3 (G.DMT.bis), ITU G.992.4 (G.lite.bis), ITU G.992.5, ITU G.992.5 Annex M, ITU G.993.2, ITU G.992.5 Annex A, ITU G.992.5 Annex L, ITU G.998.4, ITU G.993.5
- Max Transfer Rate
- 350 Mbps
Dimensions & Weight
- Width
- 26.02 cm
- Depth
- 13.5 cm
- Height
- 4.16 cm
- Weight
- 970 g
Miscellaneous
- Included Accessories
- DSL splitter
- Cables Included
- 1 x network cable ¦ 1 x phone cable
Manufacturer Warranty
- Service & Support
- Limited warranty – 3 years
Expansion / Connectivity
- Interfaces
- WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ LAN: 3 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ Phone line: 1 x DSL – RJ-11 ¦ Phone line: 1 x FXS – RJ-11 ¦ USB 2.0: 1 x
Power
- Power Device
- External power adapter
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 – 90% (non-condensing)
Software / System Requirements
- OS Provided
- No operating system
Aerial
- Aerial
- External
- Antenna Qty
- 4
Line Properties
- Line Coding Format
- 1024 QAM, OFDMA
- Framing Format
- ANSI T1.413i2
IP Telephony
- VoIP Protocols
- SIP, RTP
- Voice Codecs
- G.722, G.729ab, G.711u, G.711a, G.726
- IP Telephony Features
- Call forwarding, call transfer, Call Hold/Retrieve, call blocking, speed dial, emergency number
