TP-Link DeltaStream 16-Port Pizza-Box GPON Optical Line Terminal

Original price was: £275.99.Current price is: £91.99.

Compare
Add to wishlist
SKU: US-14991854961022 Category:
Description

TP-Link DeltaStream 16-Port Pizza-Box GPON Optical Line Terminal

  • 16 GPON Ports: Supports 1:128 splitting ratio for every port—up to 2048 ONTs by one device
  • High-Speed Uplink Ports: Provides 4× 10GE SFP+ ports and 2× gigabit uplink ports
  • Dual Redundant Power Supplies: Carrier-class reliability with dual hot-swap AC, DC, or mixed power input
  • Complete L2 & Advanced L3 Functions: Satisfies the need for numerous commercial requirements
  • Centralized Management: Via DeltaStream PON Management System (DPMS), SNMP, CLI, and WEB UI
  • Advanced L2/L2+ Functions: Static Routing, IGMP Snooping, and more meet the requirement for different applications

DeltaStream 16-port Pizza-box
GPON Optical Line Terminal

1:128 Split Ratio for High Capacity
Supports 1:128 splitting ratio for every port—up to 2048 ONTs by one device.

Redundant Dual Power Supplies
Carrier-class reliability with redundant dual power supplies supporting AC, DC or mixed power input.

Compact Size for Flexible Deployment
19 inch rack mount size is flexible and easy to deploy, suitable for different application scenarios.

Centralized Management
Makes maintenance easier with remote batch configuration and updates via DeltaStream PON Management System(DPMS), SNMP, CLI, and WEB UI.

Features
Access Control List (ACL) Yes
Maximum operating distance (GPON) 60000 m
GPON split ratio (max) 1:128
Quality of Service (QoS) support Yes
Multicast Listener Discovery (MLD) snooping Y
IGMP snooping Yes
DHCP relay Yes
DHCP server Yes
Static route Yes
Ports & interfaces
SFP/SFP+ slots quantity 4
GPON ports quantity 16
Ethernet LAN (RJ-45) ports 4
Upstream ports Gigabit Ethernet
Power
Power consumption (max) 103 W
DC voltage range 38.4 – 72 V
AC input frequency 50 – 60 Hz
AC input voltage 100 – 240 V
Operational conditions
Storage relative humidity (H-H) 5 – 90%
Operating relative humidity (H-H) 10 – 90%
Storage temperature (T-T) -40 – 70 °C
Operating temperature (T-T) 0 – 50 °C
Weight & dimensions
Height 44 mm
Depth 440 mm
Width 440 mm
General
Product family DeltaStream
  • User Guide (GPON OLT Products)
  • Regulatory Compliance (Optical Line Terminal)
  • User Guide (DeltaStream PON Management System)
  • leaflet
