TP-Link Omada PoE Splitter
- IEEE 802.3af compliant
- Selectable power output
- Gigabit speed support
- Plug-and-Play, no configuration required
The PoE Splitter POE10R (TL-POE10R) fully complies with IEEE 802.3af standard, and can work with all IEEE 802.3af PoE compliant PSE (Power Source Equipment) or PoE Supplier Adapter, such as TP-LINK’s TL-SF1008P or POE150S, or other equivalent product, to deliver 12V, 9V or 5V Direct Current to where there are no power line or outlet, where you wish to fix device such as AP, IP Camera or IP Phone, etc.
| Features | |
|---|---|
| Plug and Play | Yes |
| LED indicators | Power |
| Product colour | Black |
| Power over Ethernet (PoE) | Yes |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u |
| Ports & interfaces | |
|---|---|
| DC-out jack | Yes |
| RJ-45 output ports | 1 |
| RJ-45 input ports | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 – 40 °C |
| Storage temperature (T-T) | -40 – 70 °C |
| Operating relative humidity (H-H) | 10 – 90% |
| Storage relative humidity (H-H) | 5 – 90% |
| Certificates | |
|---|---|
| Certification | FCC, CE |
| Weight & dimensions | |
|---|---|
| Height | 24 mm |
| Depth | 54 mm |
| Width | 80.8 mm |
| Packaging content | |
|---|---|
| Quantity per pack | 1 pc(s) |
| Quick installation guide | Yes |
| Packaging data | |
|---|---|
| Package type | Box |
| Power | |
|---|---|
| Input voltage | 5, 9, 12 V |
| General | |
|---|---|
| Product family | Omada |
